SPAES GmbH & Co. KG, January 25, 2019 - Karlsruhe – For a customer in the field of air rescue SPAES GmbH & Co. KG procured and certified each nine medical racks suitable for ventilators Dräger Oxylog 3000 plus / Hamilton T1 as well as for Perfusor® Braun compact S in helicopter EC 135.
The racks for the ventilator are mounted on the track system at the ceiling of the helicopter and can be rotated by 360 degrees. This allows control and operation from all positions in the passenger compartment.
Furthermore nine double brackets suitable for infusion pump Braun Perfusor® compact S were procured, certified and installed. The medical racks are integrated by a standard rail system. SPAES adapted the standard brackets to aviation standard.
With an adapter plate the customer specific distance for installation was realized with four Dräger claws.
“The first six medical racks and the required compliance documents were delivered to the customer”, said Joachim Kies, Head of Operational Business SPAES. “The remaining twelve brackets will follow with the modification of the helicopter”, adds Kies. For installation the minor change has been created in the EASA Part J 21 design organization of SPAES.
About SPAES GmbH & Co. KG: SPAES is a growing company in the field of aviation. As a specialist for technical solutions, SPAES offers products and services for aviation. This includes the design and certification of equipment, own products and systems as well as their integration and approval in aircrafts.
The aviation products are designed, produced and certified according to European Technical Standard Order (ETSO). As an EASA Part-21J Design Organization the company offers Supplement Type Certificate (STC), Minor Change and Minor Repair in the field of avionics, cabin interior, structure and electrical systems. SPAES develops installation KIT’s for Minor Change and STC which are integrated in aircrafts by a maintenance organization Part-145.
As the requirements for design and compliance verification engineers are increasing steadily in aviation, SPAES offers special trainings in the field of small and large helicopters (CS29/27) and small airplanes (CS23). Joachim Schanz, Chief Executive Officer (CEO) of SPAES GmbH & Co. KG, founded the company in 2014 in Mannheim. Its Headquarter is situated at City Airport in Mannheim. A branch is located at Karlsruhe since 2018.
