  • AR MEKO 140A16 class

    PT Joao Coutinho class
    Corvette
    ships



    1985


    Corvette MEKO 140A16 class

    Specifications

    Login to Edit


    100crew
    1790full load (tn)
    91length (m)
    11beam (m)
    4.50draught (m)
    4000range (nm)
    27max speed (knots)
    20400power (shp)
    2Naval Engine diesel
    4Missile Launcher MM38 Exocet single launcher
    1Naval Gun Oto Melara 76 mm
    2Naval Gun twin 40 mm
    2Torpedo Launchers Mk 32 triple-tube 324mm
    1Naval Radar air search radar DA05
    1Naval Radar fire direction radar WM28
    1Naval Radar navigation radar DECCA 1226

    Aircraft

    Login to Edit

        Typical Max
    AR Argentine Navy SNIA Alouette III 11
    AR Argentine Navy EC AS555SN Fennec 2 01

    The Max option implies only aircraft of this model onboard

    Shipyards

    Login to Edit


    AR Astillero Rio Santiago (AFNE) - 6


    List of Ships

    Login to Edit

        Sorted by Year Filter:     Hide Transfers     Hide deriv.
    ARArgentine NavyP-41ARA EsporaLOML1985--
    ARArgentine NavyP-42ARA Rosales1987--
    ARArgentine NavyP-43ARA SpiroLOSP1988--
    ARArgentine NavyP-44ARA ParkerLOAP1990--
    ARArgentine NavyP-45ARA RobinsonLORB2001--
    ARArgentine NavyP-46ARA Gomez RocaLOAR2005--

    6 units


    Events

    Login to Edit

    1980OrderedAR P-46 ARA Gomez Roca as ARA Seaver
    1981-apr-1Laid downAR P-42 ARA Rosales
    1982-jan-28LaunchedAR P-41 ARA Espora
    1982-oct-2Laid downAR P-43 ARA Spiro
    1983-mar-1Laid downAR P-45 ARA Robinson
    1983-mar-4LaunchedAR P-42 ARA Rosales
    1983-jun-7Laid downAR P-46 ARA Gomez Roca
    1983-jun-24LaunchedAR P-43 ARA Spiro
    1984-mar-30LaunchedAR P-44 ARA Parker
    1984-nov-14LaunchedAR P-46 ARA Gomez Roca
    1984-nov-25LaunchedAR P-45 ARA Robinson
    1985AR P-45 ARA Robinson construction suspended
    1985AR P-46 ARA Gomez Roca construction suspended
    1985-sep-4CommissionedAR P-41 ARA Espora
    1987-mar-24CommissionedAR P-42 ARA Rosales
    1988-may-9CommissionedAR P-43 ARA Spiro
    1989RefitAR P-44 ARA Parker telescopic hangar
    1990-apr-17CommissionedAR P-44 ARA Parker
    1990-sep-25DeploymentAR P-43 ARA Spiro desert shield, desert storm
    1991-may-30AR P-43 ARA Spiro returned home
    1997-jul-18AR P-45 ARA Robinson ceremony to recommence completion activities
    1997-jul-18AR P-46 ARA Gomez Roca ceremony to recommence completion activities
    2000RefitAR P-45 ARA Robinson telescopic hangar
    2001CommissionedAR P-45 ARA Robinson
    2003RefitAR P-46 ARA Gomez Roca telescopic hangar
    2005CommissionedAR P-46 ARA Gomez Roca
