    • Guimbal Cabri G2
    • Guimbal Cabri G2

    First flew in 1992, the Cabri is a two-seat light helicopter powered by a Lycoming O-360-J2A piston engine. Entered serial production in 2005.

    As of June 2019, the global fleet of Cabri G2 have flown over 260,000 flight hours and Guimbal’ factory in Aix en Provence, France has completed the 250th helicopter




    Specifications


    Engine: 1 x Lycoming O-360-J2A 145 shp
    Capacity: 1 + 1
    Length: (m) 6.31
    Height: (m) 2.37
    Blades: 3
    Rotor diam.: (m) 7.2
    Disc area: (m2) 41
    Weight: (kgs)     Max: 700
    Speed: (km/h) Cruise: 160
    Range: (km) 700
    Ceiling: (m) 3900
    Rate/Climb: (m/min)
    blueprints


    Derivatives & Versions


    ModelYearHistory
    AH VSR700 2018 A light military rotary-wing tactical unmanned aerial vehicle, the VSR700 is being developed jointly by Airbus Helicopters and Helicopteres Guimb ...
